SBYV26C

Glass Passivated Ultrafast Rectifier, DO-41, High temperature, 600 V, 1.0 A IF

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.07~0.11 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.07~0.11

PartNumber:: SBYV26C

Brand:: Vishay Siliconix - Vishay | Pack: DO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Kate Fan's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-08

From Other Seller

Part Number:SBYV26C
US $0.07 - 0.11
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SBYV26C is a glass passivated ultrafast rectifier.

Parametrics

SBYV26C maximum ratings:(1)Maximum repetitive peak reverse voltage VRRM: 600 V; (2)Maximum RMS voltage VRMS: 420 V; (3)Maximum DC blocking voltage VDC: 600 V; (4)Maximum average forward rectified current 0.375" (9.5mm) lead length at TL = 85℃ IF(AV): 1.0 A; (5)Peak forward surge current 10ms single half sine-wave superimposed on rated load IFSM: 30 A; (6)Non repetitive peak reverse energy ERSM: 5 mJ; (7)Typical thermal resistance RθJA: 70℃/W; (8)RθJL: 16 ℃/W; (9)Operating junction and storage temperature range TJ, TSTG: -65 to +175 ℃.

Features

SBYV26C features: (1)High temperature metallurgically bonded construction; (2)Cavity-free glass passivated junction; (3)Ultrafast recovery time for high efficiency; (4)Low forward voltage, high current capability; (5)Capable of meeting environmental standards of MIL-S-19500; (6)Hermetically sealed package; (7)Low leakage current High surge current capability; (8)Specified reverse surge capability; (9)High temperature soldering guaranteed: 350℃/10 seconds, 0.375" (9.5mm) lead length,5 lbs. (2.3kg) tension.
