Product Summary
The UPD78F0338GC is a Microcontroller. The applications are: Cordless telephones, compact cameras, etc.
Parametrics
UPD78F0338GC maixmum ratings: (1)Supply voltage, VDD: -0.3 to +6.5V; (2)Vpp: -0.3 to +10.5V; (3)AV REF: -0.3 to VDD+0.3V; (4)AV SS: -0.3 to +0.3V; (5)Input voltage, VI: -0.3 to VDD+0.3V; (6)Output, VD: -0.3 to VDD +0.3V; (7)Operating ambient temperature, TA: -40 to +85℃; (8)Storage temperature, Tstg: -65 to 150℃.
Features
UPD78F0338GC features: (1)Internal memory; (2)Minimum instruction execution time changeable from high speed to ultra-low speed; (3)Instruction set suited to system control; (4)I/O port; (5)10-bit resolution A/D converter: 10 channels; (6)8-bit resolution A/D converter: 1 channel; (7)LCD controller/driver; (8)ROM correction; (9)Vectored interrupt source: 25; (10)Power supply voltage: VDD=1.8 to 5.5V.
Diagrams
 |
