The SCH5504-NS is a low barrier beam lead schottky diode designed for K-Band mixer applications.
Parametrics
SCH5504-NS absolute maxing ratings: (1)IF: 25mA; (2)VR: 4.0V; (3)PDISS: 150mW@TA=25℃; (4)TJ: -65℃ to +175℃; (5)TSTG: -65℃ to +200℃.
Features
SCH5504-NS characteristics: (1)on the condition of IR=10μA, VBR: min=4.0V; (2)on the condition of IF=-1.0mA, VF: max=375mW; (3)on the condition of IF=1.0mA, ΔVF: max=10mV; (4)on the condition of VR=1.0V, IR: max=100nA; (5)on the condition of IF=5.0mA, RD: max=20Ω; (6)on the condition of IF=5.0mA, ΔRD: max=3.0Ω; (7)on the condition of VR=0V, f=1.0MHz, CT: max=0.10pF; (8)on the condition of VR=0V, f=1.0MHz, ΔCT: max=0.02pF; (9)on the condition of Zero Bias, Zero Bias, f=10GHz, TSS: typ=-46dBm; (10)on the condition of PIN=-30dBm RL=10MΩ, γ: typ=17mV/μW; (11)on the condition of Video Badwidth=2.0MHz, RV: typ=1.4MΩ.
