Product Summary
The TN80C196KC-20 is a commercial/express CHMOS microcontroller. It is composed of the high-speed(16MHz)core as well as the following peripherals: up to 16 Kbytes of on-chip EPROM, up to 512 bytes of register RAM, 256 bytes of code RAM, an eight-channel 10-bit analog to digital converter, an(8096 compatible)asychronous/synchronous serial I/O port and so on.
Parametrics
TN80C196KC-20 absolute maximum ratings: (1)Storage temperature: -65℃ to +150℃; (2)Ambient temperature under bias: -55℃ to +125℃; (3)Voltage from VPP or EA to VSS or ANGND: -0.5V to 13.0V; (4)Voltage from any other pin to VSS or ANGND: -0.5V to 7.0V; (5)Power dissipation: 1.0W.
Features
TN80C196KC-20 features: (1)High performance CHMOS 16-bit CPU; (2)16 MHz operating frequency; (3)Up to 488 bytes of on-chip register RAM; (4)256 bytes of additional RAM(code or data RAM); (5)Regiser-register archltecture; (6)8 channel/10-bit A/D with sample/hold; (7)37 prioritized interrupt source; (8)Up to seven 8-bit(58) I/O ports; (9)Interprocessor communication slave port; (10)Watchdog timer; (11)High-speed peripheral transaction server(PTS).
Diagrams
 |
